Stab C Compact *2016-11-22T17:41:55+00:00

Stab C Compact *

The STAB-C COMPACT (Stabilizing Cradle) is a unique 5-axis stabilizing camera system which eliminates adverse motion artifacts from pan, tilt and roll. This completely silent system allows a large range of cameras, from Hi-DEF video to full size Arriflex film and digital cameras. It can be used on many types of camera cranes, camera cars, cable supports, descender rigs, telescopic cranes and helicopters, producing stable images throughout a typical 25-250mm (film lens) zoom range. Fully operational in the sitting or hanging mode, STAB-C COMPACT is able to point straight down, and features adjustable side arms to accommodate many size payloads. The STAB-C COMPACT and all its features are fully controllable via our Advanced Data Link, which can allow the head and control desk to be miles apart. Our Advanced Data Link fully integrates with any microwave, laser, RF, IR, or other communication relay systems on the market. The utmost in creativity can be attained with the STAB-C COMPACT because the roll axis is fully controllable / maneuverable, yet stabilized This system has been engineered to be fully operational in -30° F freezing weather to sweltering 120° F temperatures in the harshest of climates. In each of these extreme cases the Stab-C COMPACT system has worked perfectly, surpassing expectations every time.

  • Head Rotational Axes:
    • Pan: 360° continuous, 0-120°/sec
    • Tilt: 123°, 0-60°/sec
    • Roll: +/- 40° max; Steerable or auto level
  • Head Weight: 36kg
  • Max. Camera Weight: 39kg
  • 5 axis high bandwidth full stabilization
  • Backpan correction and targeted tracking
  • 25-500 mm film lens completely stabilized
  • Head Control: Wheels, joystick
  • Setup time: 1 hour
  • Wireless

* Available in 3D and 4K.
